| Place of Origin: | Hefei, Anhui, China |
|---|---|
| Brand Name: | Jingpu Brand |
| Certification: | CE,ROHS,ISO |
| Model Number: | JP405 |
| Minimum Order Quantity: | 500 |
| Price: | USD 0.1-5 /PCS |
| Packaging Details: | Carton packing |
| Delivery Time: | 2-7days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 200 Million per Year |
| Way To Install: | Inserting | Sensing Way: | Resistence |
|---|---|---|---|
| Output Signal Type: | Analog Type | Material: | Epoxy And Metal |
| Measuring The Dielectric: | Temperature | IP Code: | IP64 |
| Transport Package: | Carton Packing | Appearance: | White |
| Warranty: | 12~24 Months | After-sale Service: | Quality Assurance |
| Customization: | Yes | Operating Temperature: | / |
| Resistence Value: | Custom | B Value: | Custom |
| Shipping: | Shipping, Air, Or Express | Wire: | PVC/XPLE/FEP/PTFE |
| High Light: | Human Body Temperature Probe Disposable,IP64 Body Temperature Probe,Medical Temperature Sensor Disposable |
||
Brief Instruction:
The item is one disposable medical temperature sensors, it’s divided into child human body cavity temperature probe. Resistance value 2.252KΩ. Measured temperature tolerance within(25℃~45℃) ±0.1℃. Compatible for YSI400 series product instead.
Features:
Disposable
PVC sleeve
Probe with scale
Disposable Tolerance(25~45)℃±0.1℃
Operating temperature range: 0℃~50℃
7Fr(OD2.3)
Application:
It can be used in ICU, emergency room and operating room together with the body monitor to continuously monitor the temperature of the patient's body
Structure and Dimensions:(Unit:mm)
| NO. | Name | Material Specification | QTY. | Remarks |
| 1 | Chip | NTC Thermal Chip | 1 | / |
| 2 | Tube | PVCφ2.3 | 1 | white |
| 3 | Plug |
TPE(Type M2) Compatible with Molex 03-06-1023 |
1 | white |
Production of custom
After the production starts, we will not accept any modification of the order. The quantity and process are different, and the delivery time and production period are also different. The specific time period will be agreed with the sales engineer. It's usually 4-6 days. (Customized products cannot be sold again, please handle with caution!)
Settlement and delivery
After the production is finished, the goods will be delivered directly after the full payment is made. If there is any balance payment, the goods will be delivered after the payment is made. You can specify the express delivery or arrange it yourself.
